Lab 17 - Image 14

Dorsal view of isolated equine male genitalia positioned over a pelvis for reference. The deferent ducts (1) are connected by the genital fold (2) and both structures are covered by the sac like vesicular glands (3). 4, prostate gland; 5, urethralis m. covering the bulbourethral glands; 6, bulbospongiosus m.; 7, ischiocavernosus muscles covering the crura of the penis; 8, ischial tuberosity; 9, acetabulum; 10, iliac shaft; 11, iliac wing; 12, sacral tuberosity.
