Lab 2 - Image 16

Carpal cross section, the carpal canal contains the digital flexor tendons (4, 5). This canal is formed by the accessory carpal bone (1) laterally, the flexor retinaculum (2) medially, and the palmar carpal ligament (3) dorsally. 4, superficial digital flexor tendon (SDFT); 5, deep digital flexor tendon (DDFT); 6, medial palmar a.; 7, radial a.; 8, radial carpal bone; 9, intermediate carpal bone; 10, ulnar carpal bone; 11, extensor carpi radialis tendon near insertion on Mc3; 12, medial collateral ligament.
