Lab 23 - Image 5
cadaver image
labels

Cut bone rostrally and caudally to remove the zygomatic arch (1). Identify the temporal m. (2), the partially reflected masseter m. (3), the mandible (4), and the digastricus m. (5). Notice the fourth upper premolar and first lower molar teeth (asterisks).
