Lab 22 - Image 9
Bisected canine head. The pharynx is subdivided by the soft palate (1) into a nasopharynx (2), an oropharynx (3), and a laryngopharynx (4). The latter is located caudal to the soft palate and dorsal to the larynx (5). The palatopharyngeal arch (6) marks the caudal end of the soft palate. The pharyngoesophageal limen (7) marks the boundary between the pharynx and esophagus.
Identify: brain (8) in the cranial cavity, nasal septum (9), hard palate (10), root of the tongue (11) and epiglottis (12).
